Fan Filter Unit (FFU)
Product Type：CLEANROOM EQUIPMENT
Product No：MDL-1008
Thickness：Can be customized
Size：
Material：
Monthly production capacity：8000 units
Applications：Cleanrooms, semiconductor manufacturing plants, pharmaceutical workshops
Remarks：
Product Information
| Model | Specification (L×W×D) | Rated Air Volume/Air Speed (m³/h) (m/s) | Initial Resistance (Pa) | Noise (dB) | Power Supply (kW) | ||
| MDL-1008 | 1175×575×350 | 1100/0.45 | Counting Efficiency (H14) @MPPS ≥99.995% | Counting Efficiency (U15) 0.1μm ≥99.9995% | 57 | 0.18 | |
| MDL-1009 | 1175×575×350 | 1100/0.45 | 100 | 160 | 60 | 0.25 | |
| MDL-1010 | 1175×575×350 | 1100/0.45 | 100 | 160 | 63 | 0.37 | |
